Industrial Limestone Grinding Ball Mill For Cement Or Ceramic

FOB Reference Price:Get Latest Price
$15,000.00 - $65,000.00 / Sets | 1 Set/Sets (Min. Order)
Power(W):
110kw
Model Number:
Ball grinding machine
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Ball Mill
Motor Type:
AC Motor
Capacity(t/h):
10-20T
Place of Origin:
Henan, China (Mainland)
Brand Name:
Shuguang
Dimension(L*W*H):
15*1.5*1m
Weight:
10t
Certification:
ISO9001:2008
Warranty:
1 Year
After-sales Service Provided:
Video technical support, Free spare parts, Online support, Engineers available to service machinery overseas
Name:
Grinding Ball Mill
Color:
Customerized
Application:
Construction
Spare parts supplying:
Lifelong Provide
Installation:
Engineer's Guide
Feeding size:
25mm
Output size:
0.074-0.4mm
After sale service:
Engineer Avalable
The Machines classification:
Granding Mill Machine
Supply Ability
Supply Ability:
200 Set/Sets per Month
Packaging & Delivery
Packaging Details
STANDARD PACKING
Port
QINGDAO, SHANGHAI, TIANJIN

High Quality With Classifier Machine Wet  Ball Grinding Mill

Product Description

Ball Grinding Mill Description

New type Ball Grinding Mill is a key equipment for milling the materials into powders after they are crushed. It is widely used in cement, the silicate product, new type building material,fire-proof material, chemical fertilizer, black and non-ferrous metal, glass,ceramics and so on, and can make the dry and wet milling on all kinds of ores and other grindability materials.



When the Ball Grinding Mill turning, there are centrifugal force and force of friction between grinding medium and the plate in the rotary body wall. And the grinding medium will rotate with rotary body to a certain height. Then Ball Grinding Mill will fall freely under gravity, whereabouts of grinding medium, like a impact the material at the bottom to smaller size. In addition, grinding medium also generates sliding and rolling in the rotary process. Thus there are schleifwirkung among grinding medium, plate and material. So we can get fine powder in the process.



Type of Ball Grinding Mill
Energy-saving ball mill, cone ball mill, Ball Grinding Mill , batch ball mill, rod ball mill, grid ball mill, overflow type ball mill,tube ball mill, dry-type ball mill, wet ball mill, intermittence ball mill. etc.



Ball Grinding Mill Technical Parameters

Technical Data for the Ball Grinding Mill .

Type

Speed(r/min)

Ball capacity(t)

Feed size(mm)

Discharge size(mm)

Production(t/h)

Motor power(KW)

Weight(t)

900*1800

36-38

1.5

Max 20

0.075-0.89

0.65-2

18.5

0.65-2

900*3000

36

2.7

Max 20

0.075-0.89

1.1-3.5

22

5.6

1200*2400

36

3

Max 20

0.075-0.6

1.5-4.8

30

12

1200*3000

36

3.5

Max 20

0.074-0.4

1.6-5

37

12.8

1200*4500

32.4

5

Max 20

0.074-0.4

1.6-5.8

55

13.8

1500*3000

29.7

7.5

Max 20

0.074-0.4

2-5

75

15.6

1500*4500

27

11

Max 20

0.074-0.4

3-6

110

21

1500*5700

28

12

Max 20

0.074-0.4

3.5-6

130

24.7

1830*3000

25.4

11

Max 20

0.074-0.4

4-10

130

28

1830*4500

25.4

15

Max 20

0.074-0.4

4.5-12

155

32

1830*6400

24.1

21

Max 20

0.074-0.4

6.5-15

210

34

1830*7000

24.1

23

Max 20

0.074-0.4

7.5-17

245

36

2100*3000

23.7

15

Max 20

0.074-0.4

6.5-36

155

34



Ball Grinding Mill Features

1) The Ball Grinding Mill is an efficient tool for grinding many materials into fine powder;

2) The Ball Grinding Mill is used to grind many kinds of mine and other materials, or to select the mine;

3) The Ball Grinding Mill is widely used in building material, and chemical industry.

4) There are two ways of grinding: the dry way and the wet way.

5) The Ball Grinding Mill can be divided into tabular type and flowing type according to different expelling mine

6) To use the Ball Grinding Mill , the material to be ground is loaded into the neoprene barrel that contains grinding media.

7) As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours.

8) The longer the Ball Grinding Mill runs, the finer the powder will be.

9) Ultimate particle size depends entirely on how hard the material you're grinding is, and the time how long the Ball Grinding Mill runs.

10) Our Ball Grinding Mill have been used to grind glass, powder food products, create custom varnishes, make ceramic glaze, powder various chemicals

Detailed Images

Shuguang Supplying High Quality Ball Grinding Mill One Stop Service with Best Price,See the following photos for the Ball Grinding Mill .



Packaging & Shipping

Our Ball Grinding Mill have sold many countries and areas, especially Asia, Africa, and South America. Welcome to come to our factory for visiting.

Company Information

Zhengzhou Shuguang Heavy Machinery Co., Ltd. is a professional manufacturer of Ball Grinding Mill , with well-equipped testing facilities and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in industry and mining industry and other industries. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. SHUGUANG is China Top suppliers and manufacturers of Ball Grinding Mill .

1.Factory Size : 10,000-30,000 square meters, No. of Production Lines : 10

2.More than 20 years manufacturing experience

3.70% products exported in more than 130 countries

4 Long life after-service for SHUGUANG BRAND machine.

Welcome to contact with us to ask more information about the Ball Grinding Mill .
